Phrozen Penta Shield: Five-Panel Tempered Glass Enclosure for the ARCO FDM Printer
The Phrozen Penta Shield is a five-panel enclosure built from a metal frame with 5mm tempered glass, designed specifically for the Phrozen ARCO FDM 3D printer. It is an ARCO-specific accessory and is not compatible with resin printers or other FDM machines.
The Penta Shield provides three measurable performance outcomes for ARCO users. The enclosed chamber raises internal print temperature by up to 10°C above ambient, which is the thermal condition required for engineering filaments such as ABS, nylon, ASA, and carbon composites to print without warping. These materials require a stable elevated chamber temperature to prevent the differential cooling between layers that causes warping and delamination on open-frame FDM printers. Operating noise is reduced by approximately 15%, which matters for users running the ARCO in shared office, studio, or home environments. A built-in carbon-filtered fan activates automatically when internal temperature exceeds 35°C, providing controlled ventilation without manual intervention and filtering filament fumes before they exit the enclosure.
The five-panel configuration includes three transparent side panels, a transparent top panel, and a solid rear panel. Transparent panels allow visual monitoring of prints in progress without opening the enclosure. The top panel is removable for overhead access during filament loading and build plate removal. All panels are removable for maintenance access.
- Compatible printer: Phrozen ARCO FDM only
- Frame: Metal
- Panels: 5 x 5mm tempered glass (3 transparent sides, transparent top, solid rear)
- Thermal performance: Up to +10°C internal temperature increase
- Noise reduction: Approximately 15%
- Ventilation: Carbon-filtered fan, activates above 35°C
- All panels removable
3D Cast is Australia's official Phrozen distributor, stocking the Phrozen Penta Shield with fast shipping Australia wide and direct technical support.
